Forklift Drive Axle

Forklift Drive Axle - A forklift drive axle is a piece of equipment that is elastically affixed to a vehicle framework using a lift mast. The lift mast is attached to the drive axle and can be inclined round the axial centerline of the drive axle. This is done by at the very least one tilting cylinder. Forward bearing elements together with back bearing parts of a torque bearing system are responsible for fastening the vehicle and the drive axle frame. The drive axle could be pivoted around a swiveling axis oriented transversely and horizontally in the vicinity of the rear bearing parts. The lift mast is also capable of being inclined relative to the drive axle. The tilting cylinder is connected to the vehicle frame and the lift mast in an articulated fashion. This allows the tilting cylinder to be oriented practically parallel to a plane extending from the swiveling axis to the axial centerline.

Unit H40, H45 and H35 forklifts, which are produced by Linde AG in Aschaffenburg, Germany, have a mounted lift mast tilt on the vehicle frame itself. The drive axle is elastically affixed to the frame of the forklift utilizing numerous various bearings. The drive axle comprise tubular axle body together with extension arms affixed to it and extend rearwards. This type of drive axle is elastically attached to the vehicle frame by back bearing parts on the extension arms together with forward bearing tools located on the axle body. There are two back and two front bearing devices. Each one is separated in the transverse direction of the forklift from the other bearing device in its respective pair.

The drive and braking torques of the drive axle are sustained through the rear bearing components on the frame using the extension arms. The load and the lift mast produce the forces which are transmitted into the road or floor by the frame of the vehicle through the drive axle's anterior bearing components. It is essential to make certain the parts of the drive axle are installed in a firm enough way to be able to maintain immovability of the lift truck truck. The bearing parts could reduce slight road surface irregularities or bumps all through travel to a limited extent and provide a bit smoother operation.
